Speaker microphone IP56 for Motorola MTP850FUG, MTP6650, DP3400-DP4800, Nexus

Robust speaker microphone for Motorola radios


The XSMP5000M10-MSC-Y speaker microphone is compatible with Motorola radios MTP850FUG, MTP6650, MTP850FUG, MTP6650, DP3400, DP3401, DP3600, DP3601, DP4400, DP4401, DP4600, DP4601, DP4800, DP4801 and is suitable for wet and harsh environments (IP56).

Compared to dynamic microphones, speaker microphone impress with their high sound quality. Built-in condenser microphones reduce background noise and powerful built-in speakers ensure clear communication. The Axcom control units consist of a robust, partially rubberized housing and are easy to operate thanks to their intuitive design. A large transmit button on the top makes it easy to operate even when wearing gloves and its eye-catching yellow color makes it easy to see even in the dark or in poor visibility conditions. A 360° rotatable fastening clip with 8 notches allows you to attach the control unit perfectly. A high-quality PU cable and anti-kink sleeves ensure long-term use. Additional accessories can be connected via a 7.1 mm Nexus connection, including the MSA-C1 headset. The temperature range is between -40°C and +80°C.

Your advantages at a glance:

• High sound quality thanks to condenser microphone
• Easy to operate, even with gloves or in the dark
• High-quality components for a long service life
• Particularly good price-performance ratio
• 12 months warranty

Technical information:

Nexus Savox assignment

1-microphone solution

Weight: 200g
Dimensions: 101.0 x 66.7mm
Mounting clip dimensions: 54.2 x 22.2mm
Cable length: 500mm
Cable cross-section: Ø5.5mm
Cable material: PU

Electronic data:

Microphone dimensions: Ø6.0 x 5.0mm
Sensitivity: -45dB +- 3dB
Loudspeaker dimensions: Ø40mm
Impedance: 8Ohm +- 15%
Maximum power: 1.0W

Compatible with:

Motorola MTP850FUG

Motorola MTP6650

Motorola DP3400, DP3401

Motorola DP3600, DP3601

Motorola DP4400, DP4401,

Motorola DP4600, DP4601

Motorola DP4800, DP4801

MSA Auer C1
